Estimate delivery times: 2-3 days (All Over Pakistan), 24 Hours (Lahore).
Return within 7 days of purchase. Duties & taxes are non-refundable.
Guarantee Safe Checkout
Included Equipment | CD with software, Smart UPS signalling RS-232 cable, User manual, USB cable |
---|---|
Performance Multiplier | 1 |
Number of Tare Power | 30 W |
Number of Power Module Free Slots | 0 |
Number of Power Module Filled Slots | 0 |
Redundant | No |
UPS Size | S (Internetworking, Server, Telecom) |
Value Multiplier | 1 |
Number of Rack Units | 0U |
Color | Black |
Dimensions | Depth: 43.9 cm, Height: 21.6 cm, Width: 17 cm |
Mounting Location | Front |
Mounting Preference | No preference |
Net Weight | 18.86 kg |
Mounting Mode | Not rack-mountable |
Two Post Mountable | 0 |
USB Compatible | No |
Network Frequency | 50/60 Hz +/- 3 Hz auto-sensing |
Plug Standard | IEC 320 C14 |
Input Voltage Limits | 151...302 V adjustable, 160...286 V |
Input Voltage | 230 V |
Rated Power (W) | 670 W |
Maximum Configurable Power (W) | 670 W |
Harmonic Distortion | Less than 5% at full load |
Output Frequency | 47...53 Hz for 50 Hz nominal sync to mains, 57...63 Hz for 60 Hz nominal sync to mains |
Crest Factor | Up to 5 : 1 |
UPS Type | Line interactive |
Wave Type | Sine wave |
Number of Power Socket Outlets | 8 IEC 320 C13, 2 IEC Jumpers |
Efficiency Curve | Load: 0% - 100%, Efficiency: 50% - 100% |
Output Voltage | 230 V |
Maximum Configurable Power (VA) | 1000 VA |
Rated Power (VA) | 1000 VA |
Product Certifications | C-Tick, CE, GOST, VDE |
Standards | EN 50091-1, EN 50091-2 |
Operating Temperature | 0 - 40 °C |
Relative Humidity | 0 - 95 % |
Operating Altitude | 0 - 10000 ft |
Storage Temperature | -15 - 45 °C |
Storage Relative Humidity | 0 - 95 % |
Storage Altitude | 0 - 15240 m |
Acoustic Level | 41 dBA |
Heat Dissipation | 100 Btu/h |
Battery Type | Lead-acid battery |
Battery Recharge Time | 3 hours |
Battery Replacement Quantity | 1 |
Battery Charger Power | 88 W rated |
Battery Power (VAH) | 264 VAh runtime |
Battery Life | 3 - 5 years |
Extended Runtime | 0 |
Free Slots | 1 |
Control Panel | LED status display with load and battery bar-graphs and online, on battery, replace battery, and overload indicators |
Alarm | Alarm when on battery, low battery alarm, configurable delays |
Emergency Power Off | Optional |
Surge Energy Rate | 320 J |
Noise Suppression | Full-time multi-pole noise filtering, 0.3% IEEE surge let-through, zero clamping response time, meets UL 1449 |
